10L Laboratory High Shear Mixer Cosmetic Cream Making Machine With Lifting System

Brand Name:	APVO
Model Number:	RHJ-A10
MOQ:	1 set
Price:	USD$8500/set
Packaging Details:	Standard wooden case

Detail Information

Product Description

Detail Information

Place of Origin:

Yangzhou, China

Capacity:

Speed:

0-3000rpm

Working:

High Speed Mixer

Heating Method:

Steam/Electric Heating Method

Lift:

Hydraulic Lift

Machine Material:

Stainless Steel 304 / SUS316L

Scraper:

0-63rpm

Condition:

Warranty:

1 Year

Highlight:

10L Laboratory High Shear Mixer

10L Cosmetic Cream making machine

High Shear Mixer with Lifting System

Product Description

10L Laboratory High Shear Mixer Cosmetic Cream Making Machine With Lifting System

Capacity	10L
Speed	0-3000rpm
Working	High Speed Mixer
Heating method	Steam/Electric Heating Method
Lift	Hydraulic lift
Machine Material	Stainless Steel 304 / SUS316L
Scraper	0-63rpm
Condition	New
Warranty	1 year

Product Overview

The 10L Laboratory High Shear Mixer is designed for producing stable emulsions, creams, milk, gels, balms, lotions, ointments, and toothpastes with extremely small particles. Ideal for chemical, cosmetics, and food industries, this machine is perfect for cosmetic factories and pharmaceutical facilities requiring precise homogenization.

Working Principle

Materials in the water-phase and oil-phase tanks are heated and stirred before being transferred to the emulsifying tank via vacuum pump. The central paddle and PTFE scraper thoroughly mix the materials while pushing them down to the high-speed emulsifier. This process creates particles between 200nm - 2um while vacuum conditions remove any bubbles.

Technical Specifications

Model	Main pot	Water pot	Oil pot	Main pot wall scraping	Main pot homogenizer	Water oil pot (kw)	Hyraulic system	Vacuum pump power
RHJ-A5L	5L	-	-	0.18	1.1	--	0.75	0.55
RHJ-A10L	10L	8	5	0.18	1.1	0.18	0.75	0.75
RHJ-A20L	20L	18	10	0.37	1.5	0.18	0.75	0.75
RHJ-A50L	50L	40	25	0.75	4-7.5	0.75	1.5	1.5
RHJ-A100L	100L	80	50	1.5	4-7.5	1.1	1.5	1.5
RHJ-A200L	200L	170	100	2.2	7.5-11	1.5	1.5	2.2
RHJ-A300L	300L	250	150	2.2	7.5-11	1.5	1.5	2.2
RHJ-A500L	500L	420	250	4	11	2.2	1.5	2.2
RHJ-A1000L	1000L	820	500	5.5	15	2.2	2.2	3

Key Features

SIEMENS frequency converter for precise speed adjustment to meet various production requirements
Vacuum defoaming system ensures aseptic conditions and prevents dust contamination
Mechanical sealing provides excellent sealing effect and extended working life
Mirror-polished tank body and pipes fully comply with GMP standards
All material contact parts made from high-quality SUS316L stainless steel
Optional electric or steam heating methods available
Advanced PLC touch screen control available as an option
Hydraulic lifting system for easy cleaning and maintenance

Frequently Asked Questions

How can I verify your product quality if I'm not in China?

With 20 years of manufacturing experience, we have helped numerous customers improve their business operations through our reliable equipment.

What quality control measures do you implement?

We conduct pre-production sampling before mass production and perform final inspections before shipment to ensure product quality.

What other equipment do you offer?

Our product range includes Vacuum Homogeneous Emulsifying Machines, Homogenizing Mixers, Reverse Osmosis Water Treatment Systems, and various Filling Machines.

Why choose APVO equipment?

We specialize in high-quality, efficient equipment with excellent performance. Our science-first approach and dedicated after-sale service team have earned us consistent customer recognition.
